VideosValco/Vici compatible Stainless Steel Sample Loops
Valco-Compatible Stainless Steel Loops are manufactured by IDEX Health & Science. These loops are designed for use with Valco valve models CW6 and EC6W. Each loop has burr-free, polished ends and is passivated and flushed with reagent-grade methanol to ensure cleanliness. Loops made with 1/16” OD tubing come complete with F-287 SealTight™ Fittings, which are pressure rated to 9,000 psi (620 bar). Actual pressure rating depends on the valve and the ports inside the valve.The fittings and adapters that accompany the 1/8” OD sample loops are rated to 1,000 psi (69 bar). Volumes are stated at ±10%, with exact calibration services available. Each sample loop we calibrate is documented and supplied with a calibration certificate.
| Valco/Vici compatible Stainless Steel Sample Loops | ||||
| Part No. | UOM | Volume | Dimenstion | Valco No. |
| 1750 | EA | 5 ?L | 0.18 mm (0.007”) ID x 1/16” OD | SL5CW |
| 1751 | EA | 10 ?L | 0.25 mm (0.010”) ID x 1/16” OD | SL10CW |
| 1752 | EA | 15 ?L | 0.25 mm (0.010”) ID x 1/16” OD | SL15CW |
| 1755 | EA | 20 ?L | 0.51 mm (0.010”) ID x 1/16” OD | SL20CW |
| 1758 | EA | 25 ?L | 0.51 mm (0.010”) ID x 1/16” OD | SL25CW |
| 1759 | EA | 50 ?L | 0.51 mm (0.010”) ID x 1/16” OD | SL50CW |
| 1762 | EA | 100 ?L | 0.51 mm (0.010”) ID x 1/16” OD | SL100CW |
| 1778 | EA | 200 ?L | 0.76 mm (0.030”) ID x 1/16” OD | - |
| 1763 | EA | 250 ?L | 0.76 mm (0.030”) ID x 1/16” OD | SL250CW |
| 1764 | EA | 500 ?L | 0.76 mm (0.030”) ID x 1/16” OD | SL500CW |
| 1770 | EA | 1 mL | 0.76 mm (0.030”) ID x 1/16” OD | SL1KCW |
| 1772 | EA | 2 mL | 1.02 mm (0.040”) ID x 1/16” OD | SL2KCW |
| 1775 | EA | 5 mL | 2.03 mm (0.080”) ID x 1/8” OD | SL5KCW |
| 1776 | EA | 10 mL | 2.03 mm (0.080”) ID x 1/8” OD | SL10KCW |
